AB1DK23L-9101

Automann’s premier air spring boasts the ability to maintain ride height. Engineered to meet OEM specification while minimizing vibration and load fluctuations. The Air Spring is guaranteed to ensure a smooth ride for driver and cargo alike. Enjoy a quiet and level ride experience with these long lasting Air Springs. Committed to Keeping Trucks Moving

• Quality raw material and manufacturer expertise to guarantee performance
• Plastic Base allows for optimized weight and cost savings
• Features OEM dimensioning for hassle-free assembly
• Resistant to oil, lubricants, and averse weather conditions
• Manufactured to be environmentally friendly and longer lasting

Product Specifications

• Type: Rolling Lobe
• Load (Lbs) @ 80 PSI: 5700
• Load (Lbs) @ 100 PSI: 7200
• Natural Freq. (CPM): 60
• Design Height (In): 15.50
• Bottom Plate Type: Plastic
• Top Plate Hole/Stud Qty: 2
• Top Plate Dia. : 9.00
• Top Plate C to C Dia.: 5.50
• Bottom Plate Hole/Stud Qty: 4
• Bottom Plate Dia.: 10.28
• Bottom Plate C to C Dia.: 7.87
• Bottom Part #: BS08129
• Bumper: Yes
• Bracket: N/A
• Min. Height: 9.90
• Max. Height: 24.60
• Max. Dia.: 12.60

Cross References: 64279, 910-19P315, 5181508214, 518-15082-14, 9101, W013589101, W01-358-9101, 1T12103, 1R12-103, 1R12113, 1R12-113, B3842, B-3842, S10443, S3842, S-3842, 554768C1, SC2038, 23AS83, 90044201, 9044701, 90054218, 90054218, 90057008, 90557008, 90557009, 90557043, 90557082, AR14151F, AR14151G, 1KK36, 10590, 1288301, 12883-01, 1003589101C, S5828C, S740C, AS5049101, 63647, 3130490, 85101149, AS0040
